12/24V LED Marker Light with Indicator - Amber

12/24V LED Marker Light with Indicator - Amber - LG146

GENERAL CHARACTERISTICS

• LED 3 Function Side Marker Light With Removable Bracket
• Housing: H/D Plastic
• Application: on road as well as off-road
• 1 pcs x 1.25 watt high intensity OSRAM LEDs
• Lamp finish: PMMA
• Lifespan: 30,000 hours +
• Water tightness: Splashproof (IP67)
• Pre Wired
• ECE Approved / emark Certified
• EMC - Radio Suppression

TECHNICAL LIGHT PROPERTIES

• Light color: Amber
• Color temperature: 6000K.
• Side Clerance 12/24V 1.0W / 2.0W
• Indicator (cat,5) 12/24V 1.0W / 2.0W
• Side Reflector

ELECTRICAL CHARACTERISTICS

• Nominal lamp power: 1.25 Watt
• 1 pcs 1.25 watt high intensity OSRAM LEDs
• Suitable for 12-36V DC
• 21.4 lumens
• Ground - White
• Clearance - Black
• Indicator - Yellow

DIMENSIONS IN MM.

• Lamp width: 110 mm
• Lamp height: 75 mm
• Lamp thickness: 29 mm

Sidemarker lightsare types oflightthat are attached to the front and rear sides of motorized vehicles and trailers. Their function is to add some morelightsalong with the headlights for the drivers to see and drive safely.

Our full range ofLED Marker Lightsare manufactured to thehighest qualityin Europe. By using high classOsram Diodes, the Marker outputs excellent light and has a huge lifetime. The Marker Light range is suitable for a wide range of Vehicles & machinery such asTrucks,Trailers,Agricultural Equipment& Construction Vehicles.
